LER-4027-BAV - DISCONTINUED

Rack: Configurable top with 12U opening includes riveted 10-32 threaded rails for 19 in. panels Welded sides with vents Includes rear door with vents and key lock Fully adjustable front rails tapped 10-32 Multiple lacing points, laser-cut knockout panels Pilot Point screws with captive washers Grounding stud Beveled corners Black textured powder coat finish   Accessory Bundle: Solid surface-mount front door with key lock (LFD-40) 1 pair 40U rear rails tapped 10-32 (RRD-40) Two 32″L power strips each with 12 (15A/20A) outlets, surge suppression, 12′ cord and NEMA 5-20P plug (ACS-2012) 7U fan panel with four whisper fans (FW4-7) Straight bars (4) and 4″ offset bars (2) for cable management (CMBS Series) 35U vertical cable manager (CMV3-40) Heavy-duty leg levelers (LL) Magnetic vent blocker kit (MVB27) Velcro cable wraps (VCW-12) Two extra bags of rack screws Rack Space:  40U Height:  76.125 in. Width:  23.06 in. Depth:  27.00 in. (24.34 usable) Load Capacity: 3150 lbs. Rack Spec Sheet:  LER / LSER Series Accessory Bundle Spec:  1688-LER4027BAV CSI 3-part specification sheet (rack only):  LER-3P CAD drawings:  LER-4027 Revit Models:  LER Series Install:  20055-FloorRack RACK: TAA Compliant EIA/TIA Compliant UL 2416 Listed Certified U.S. Steel Made in U.S.A. (BAA) The EIA/TIA compliant 19″ floor rack shall be Lowell model LER-4027-BAV with overall dimensions of 76.125″H x 27.00″D x 23.06″W; usable height of 40 rack units, and usable depth of 24.34″. Rack construction shall be fully welded certified U.S. steel with 16-gauge frame and 14-gauge bottom reinforced at load-bearing junctions, all with black textured powder coat finish. Welded sides shall feature vents at top and bottom. The rack shall include a recessed rear door with vents and key lock, laser-cut knockout panels above and below door with 1/2″–3/4″ and 1″–1-1/2″ EKO for conduit, and 1/2″ KO for wireless antennae above door. The front shall feature vents along top and bottom. The top shall feature a 12U opening with riveted 10-32 threaded rails on 19″ E.I.A. spacing. Rack bottom shall have an opening measuring 22.88″ x 19.94″ and include a grounding stud. Rack shall include 1 pair of (40U) adjustable 11-gauge steel rails tapped 10-32 on 19″ E.I.A. spacing with black finish and numbered rack unit increments. The UL 2416 Listed rack shall be manufactured in the U.S.A. with a UL Listed load capacity of 3150 lbs   The rack shall include a bundle of accessories that shall consist of a solid surface-mount front door with key lock (LFD-40), a pair of 40U rear rails (RRD-40), two 32″L power strips–each with (12) 15A/20A outlets with surge suppression and 12′ cord (ACS-2012), a 7U fan panel with four whisper fans (FW4-7), 4 straight bars and 2 offset bars from CMBS cable management series, a 40U vertical cable management bar (CMV3-40), set of leg levelers (LL), a magnetic vent blocker kit (MVB27), a pack of velcro cable wraps (VCW-12), and two extra bags of screws.
